NanoPi NEO Air H3 Quad-Core Development Board - 512MB RAM
$42.9500
In stock
SKU
MIN-07-006
Volume discounts:
- +10 4 % $41.3300
- +25 6 % $40.5100
- +50 8 % $39.7000
- +100 9 % $38.8900
- +300 11 % $38.0800
Add an Accessory:
-
CH340G USB to TTL Converter$0.7400 - FT232RL FTDI 3.3V/5V Mini USB to TTL Serial Converter Adapter Module$1.7700
View more
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
NanoPi NEO H3 Quad-Core Development Board - 256MB RAM Previous
NanoPi NEO Air is a compact quad-core development board with 512MB RAM and 8GB eMMC storage. It is built around the Allwinner H3 processor with a Quad-core Cortex-A7 CPU up to 1.2GHz. The board includes Mali400MP2 graphics at 600MHz with OpenGL ES2.0 support. Wireless connectivity includes WiFi 802.11b/g/n and Bluetooth 4.0 dual-mode. It also provides Ethernet, USB, GPIO, and serial debug connections for electronics and robotics projects. Supported operating systems include u-boot, UbuntuCore, and flasher.
Features of NanoPi NEO Air H3 Quad-Core Development Board - 512MB RAM, 8GB eMMC
- Allwinner H3 processor
- Quad-core Cortex-A7 CPU
- 512MB DDR3 RAM
- 8GB eMMC storage
- WiFi 802.11b/g/n
- Bluetooth 4.0 dual-mode
- 10/100M Ethernet
- 2 USB hosts
- Micro USB power and OTG support
- 4-pin serial debug header
- GPIO1 expansion pins
- GPIO2 expansion pins
Specifications of NanoPi NEO Air H3 Quad-Core Development Board - 512MB RAM, 8GB eMMC
- Processor: H3
- CPU: Quad-core Cortex-A7 @ 1.2GHz
- GPU: Mali400MP2 @ 600MHz
- OpenGL ES2.0 support
- Memory: DDR3 RAM 512MB
- Storage: 8GB eMMC
- Network: 10 / 100M Ethernet
- WiFi: 802.11b/g/n
- Bluetooth: 4.0 dual mode
- 2 USB hosts
- Micro USB: Power and OTG support
- Debug serial: 4 pin, 2.54 mm pin headers
- GPIO 1: 24 pins, 2.54 mm, UART, SPI, I2C, GPIO
- GPIO 2: 12 pins, 2.54 mm, USBx2, IR, SPDIF, I2S
- Dimensions: 40x40mm
- Weight: 7.5g
- Power supply: 5V/2A
- Operating systems: u-boot, UbuntuCore
How to Use NanoPi NEO Air H3 Quad-Core Development Board - 512MB RAM, 8GB eMMC
- Provide 5V/2A power through the micro USB port or the two-pin input.
- Connect the required peripherals through USB, GPIO, or the serial debug header.
- Install and run the supported operating system on the board.
More Info
- Board size: 40x40mm
- Board weight: 7.5g
| Processor (SoC) | Allwinner H3 |
|---|---|
| CPU | Quad-core [email protected] |
| Architecture | ARM Cortex-A7 |
| RAM | 512MB |
| RAM Type | DDR3 |
| Storage Support | microSD, eMMC |
| Storage Capacity | 8GB eMMC |
| GPU/VPU | Mali400MP2 @ 600MHz |
| Ethernet | 100 Mbps |
| Wi-Fi | WiFi 4 |
| Bluetooth | Bluetooth 4.0 |
| USB Ports | 2x USB Host, 1x Micro USB OTG |
| Video Output | No |
| Hardware Interfaces | I2C, SPI, UART |
| GPIO Pins | 36 pins (24-pin + 12-pin headers) |
| Camera/Display | No |
| Power Input | 5V/2A |
| PCIe | No |
| Dimensions (mm) | 40x40mm |
| OS Support | Linux, Ubuntu |
| Weight (g) | 7.5g |
