NanoPi M1 Quad-Core Development Board - 512MB RAM
$40.9500
In stock
SKU
MIN-07-005
Volume discounts:
- +10 3 % $39.6600
- +25 5 % $39.0200
- +50 6 % $38.3700
- +100 8 % $37.7300
- +300 9 % $37.0800
Add an Accessory:
-
CH340G USB to TTL Converter$0.7400 - FT232RL FTDI 3.3V/5V Mini USB to TTL Serial Converter Adapter Module$1.7700
View more
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
NanoPi NEO Air H3 Quad-Core Development Board - 512MB RAM Previous
The NanoPi M1 is a compact quad-core development board built around the Allwinner H3 processor. It includes 512MB DDR3 RAM and a range of integrated interfaces for embedded and educational electronics projects. The board provides Ethernet, HDMI, AV, USB, and GPIO connectivity in a 64×50mm form factor. It also includes an onboard microphone, IR receiver, and power and reset buttons. Supported operating systems include u-boot, Debian, Ubuntu-MATE, and Ubuntu-Core.
Features of NanoPi M1 Quad-Core Development Board - 512MB RAM
- Allwinner H3 processor
- Quad-core Cortex-A7 CPU
- 512MB DDR3 RAM
- 10/100M Ethernet
- Onboard microphone
- IR receiver included
- Three USB 2.0 Type-A ports
- Raspberry Pi compatible 40-pin GPIO header
Specifications of NanoPi M1 Quad-Core Development Board - 512MB RAM
- Processor: Allwinner H3
- CPU: Quad-core Cortex-A7 @ 1.2GHz
- GPU: Mali400MP2 @ 600MHz
- OpenGL ES 2.0 support
- Memory: 512MB DDR3 RAM
- Networking: 10/100M Ethernet
- Audio: 3.5mm audio jack
- Audio: HDMI output
- Microphone: Onboard microphone
- IR Receiver: Included
- USB Ports: Three USB 2.0 Type-A hosts
- Micro USB: Supports power and OTG functionality
- Video Output: HDMI 1.4
- Video Output: CVBS
- Camera Interface: 24-pin DVP connector
- Camera Interface: 0.5mm pitch
- HDMI Connector: One HDMI 1.4A Type-A
- Serial Debug: 4-pin header
- Serial Debug: 2.54mm pitch
- GPIO: 40-pin 2.54mm header
- GPIO: Raspberry Pi compatible
- GPIO: UART
- GPIO: SPI
- GPIO: I2C
- GPIO: PWM
- GPIO: IO
- Buttons: Power
- Buttons: Reset
- Dimensions: 64×50mm
- Power Supply: 5V/2A
- Supported OS: u-boot
- Supported OS: Debian
- Supported OS: Ubuntu-MATE
- Supported OS: Ubuntu-Core
How to Use NanoPi M1 Quad-Core Development Board - 512MB RAM
- Connect the 5V/2A power supply.
- Use the available interfaces such as HDMI, USB, Ethernet, GPIO, or Micro USB as needed.
- Load one of the supported operating systems.
More Info
- Compact board size: 64×50mm
- Includes power and reset buttons
- Designed with a 40-pin GPIO layout
| Processor (SoC) | Allwinner H3 |
|---|---|
| CPU | Quad-core Cortex-A7 @ 1.2GHz |
| Architecture | ARM Cortex-A7 |
| RAM | 512MB |
| RAM Type | DDR3 |
| Storage Support | microSD |
| GPU/VPU | Mali400MP2 |
| Ethernet | 100 Mbps |
| Wi-Fi | No |
| Bluetooth | No |
| USB Ports | Three USB 2.0 Type-A hosts |
| Video Output | HDMI |
| Hardware Interfaces | CSI (Camera), I2C, SPI, UART |
| GPIO Pins | 40-pin 2.54mm header |
| Camera/Display | CSI (Camera) |
| Power Input | 5V/2A |
| PCIe | No |
| Dimensions (mm) | 64×50mm |
| OS Support | Linux, Ubuntu, Debian, Android |
