L298N Dual-Channel Bipolar DC/Stepper Motor Driver Board
$1.3500
In stock
SKU
MTR-09-001
Volume discounts:
- +50 5 % $1.2800
- +100 7 % $1.2500
- +300 10 % $1.2100
- +500 13 % $1.1800
- +1000 16 % $1.1400
Product Variations:
-
L298N Dual-Channel DC/Stepper Motor Driver
MTR-09-003 - L293D Motor Driver Shield for Arduino
ARD-02-044 - L298N Dual-Channel Bipolar DC/Stepper Motor Driver
MTR-09-001 - 7A 160W Dual Channel DC Motor Drive Module (Replac
MTR-08-023 - L298P Dual Channel Arduino Motor Driver Shield
ARD-02-002 - L298P H-bridge Arduino Motor Driver Shield with Bu
ARD-02-003
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
Ywrobot 3D printer Dual Stepper Motor Drive Expansion Board 8825 / A4988 Previous
The L298N Dual-Channel Bipolar DC/Stepper Motor Driver Board is a dual H-bridge motor driver for DC motors and 4-phase stepper motors. It supports bidirectional control for two motors or one stepper motor. The board operates with a 5V to 35V supply range and uses a 5V TTL-compatible logic voltage. It includes forward, reverse, brake, and standby control modes. Built-in protection diodes help prevent back EMF voltage spikes. The board uses screw terminals for motor connections and is designed for robotics and electronics projects.
Features of L298N Dual-Channel Bipolar DC/Stepper Motor Driver Board
- Dual H-bridge motor driver
- Two motor control support
- Bidirectional operation
- 5V TTL-compatible logic
- Built-in protection diodes
- Screw terminal connections
Specifications of L298N Dual-Channel Bipolar DC/Stepper Motor Driver Board
- Motor Driver Chip: L298N dual H-bridge motor driver
- Operating Voltage: 5V - 35V
- Peak Current: 2A per channel (continuous), 3A per channel (peak)
- Logic Voltage: 5V (TTL compatible)
- Control Modes: Forward, Reverse, Brake, and Standby
- Motor Types: DC motors and 4-phase stepper motors
- Built-in Protection Diodes: Prevent back EMF (flyback) voltage spikes
- Dimensions: 43x43x27 mm (about 1.75"x1.75"x1")
- Weight: 30 g
- Storage Temperature: -20 to +135 °C
- Maximum Power: 25W
- Mounting: Screw terminals for motor connections
How to Use L298N Dual-Channel Bipolar DC/Stepper Motor Driver Board
- Connect the motors to the screw terminals with the correct polarity.
- Apply the logic voltage and motor supply within the specified ratings.
- Select the required control mode for forward, reverse, brake, or standby operation.
More Info
- When driving voltage is 7V to 12V, the on-board 5V logic voltage can be used as a power supply.
- When driving voltage is higher than 12V and up to 24V, remove the on-board 5V output enable jumper and connect 5V to the external 5V output port.
| Weight (g) | 30 |
|---|
