SHT35 Temperature and Humidity Sensor Module - I2C Interface
$8.9500
In stock
SKU
SEN-10-050
Volume discounts:
- +25 4 % $8.5900
- +50 6 % $8.4100
- +100 8 % $8.2300
- +300 10 % $8.0400
- +500 12 % $7.8600
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
SHT31 Temperature and Humidity Sensor Module - I2C Interface Previous
SHT35 Temperature And Humidity Sensor Module is a digital temperature and humidity sensor module with an I2C interface. It is part of the SHT3X series and is designed for accurate environmental measurement. The module supports a wide operating voltage range and provides calibrated sensing performance. It is suitable for electronics and robotics projects that require temperature and humidity data. The pin header is soldered and uses a 90-degree pin header.
Features of SHT35 Temperature And Humidity Sensor Module - I2C, 2.4-5.5V
- Digital temperature and humidity sensing
- I2C interface output
- Wide operating voltage range
- Calibrated sensor design
- 90-degree soldered pin header
Specifications of SHT35 Temperature And Humidity Sensor Module - I2C, 2.4-5.5V
- Operating voltage: 2.4 to 5.5 V
- Humidity measurement accuracy: ±1.5%
- Temperature measurement accuracy: ±0.2 °C
- Interface: I2C
- Operating humidity: 0-100% RH
- Operating temperature: -40 to 90 °C
- Size: 12x12 mm
- Pin header type: 90-degree pin header
- Pin header condition: soldered
How to Use SHT35 Temperature And Humidity Sensor Module - I2C, 2.4-5.5V
- Connect the module using the I2C interface.
- Apply power within the specified operating voltage range.
- Read temperature and humidity values from the sensor.
More Info
- SHT3X series sensor module
- Series includes SHT30, SHT31, and SHT35
| Interface Type | I2C |
|---|---|
| Operating Voltage (V) | 2.4 to 5.5 V |
| Operating Current (mA) | 0.8 mA (active), 0.2 uA (idle) |
| Operating Temp (°C) | -40 to 90 °C |
| Dimensions (mm) | 12 x 12 mm |
| Mounting Type | Side-mounted, right-angle design |
| Output Type | I2C |
| Accuracy | ±1.5% RH, ±0.2 °C |
| Resolution | 0.01 °C, 0.01% RH |
| Response Time | 8 s (tau 63%) |
| Measurement Range | Temperature: -40 to 90 °C, Humidity: 0-100% RH |
| Environmental Parameter | Temperature And Humidity |
| Chipset | SHT35 |
| Humidity Range | 0-100% RH |
| Relay Output | No |
| Humidity Accuracy | ±1.5% |
| Protocols | I2C |
| Temp Accuracy | ±0.2 °C |
