Raspberry Pi Infrared Night Vision Camera Module 8Mp V2.1
$92.5000
In stock
SKU
MIN-01-073
Volume discounts:
- +5 2 % $90.3500
- +10 3 % $89.2800
- +25 5 % $88.2000
- +50 6 % $87.1300
- +100 7 % $86.0500
Product Variations:
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
Pixy2 CMUcam5 Image Sensor - Arduino Compatible (made in China) Previous
Raspberry Pi Infrared Night Vision Camera Module 8MP V2.1 is a camera module for Raspberry Pi and compute modules. It supports HD video and still image capture. The module uses an infrared-free design for night photography and video recording. It is based on the Sony IMX219PQ image sensor and is designed for fast video imaging and high sensitivity. Auto exposure, white balance, and brightness detection functions are included. A 15 cm ribbon cable is attached for CSI connection. For Raspberry Pi 5 and Zero, a different flat cable is required.
Features of Raspberry Pi Infrared Night Vision Camera Module 8MP V2.1
- No infrared filter
- 8MP fixed-focus camera
- Sony IMX219PQ image sensor
- 1080p, 720p60, and VGA90 support
- 15-pin flat cable
- Auto exposure control
- White balance control
- Brightness detection
Specifications of Raspberry Pi Infrared Night Vision Camera Module 8MP V2.1
- Module type: Camera module
- Channels: 1
- Supported bus interface: CSI-2
- Maximum supported resolution: 3280x2464 pixels
- Maximum frame rate: 30fps
- Dimensions: 23.86x25x9 mm
- Maximum operating temperature: +60°C
- Minimum operating temperature: -20°C
- CCD size: 1/4inch
- Aperture (F): 2.0
- Focal Length: 3.05mm
- Field of View: 73.8 degree
- Still picture resolution: 3280 × 2464
- Support 1080p30 video record
- Support 720p60 video record
- Support 640x480p90 video record
- No infrared filter
- Infrared LED is required to provide Infrared lighting for night vision
How to Use Raspberry Pi Infrared Night Vision Camera Module 8MP V2.1
- Connect the 15 cm ribbon cable to the Raspberry Pi CSI port.
- Use the correct flat cable for Raspberry Pi 5 or Zero.
- Access the camera through MMAL, V4L, or Picamera Python.
More Info
- Compatible with Raspberry Pi revisions and compute modules.
- Suitable for HD image and video capture.
- Supports night vision operation with infrared lighting.
| Interface Type | MIPI |
|---|---|
| Operating Voltage (V) | 3.3V |
| Operating Temp (°C) | -20 to 60 |
| Dimensions (mm) | 23.86x25x9 mm |
| Mounting Type | Screw holes |
| Output Type | Digital |
| Resolution | 3280x2464 pixels |
| Pixel Resolution | 8MP |
| Chipset | IMX219PQ |
| Qty | 1 |
| Sensor Type | CMOS |
| Output Interface | Digital |
| Application | Night Vision |
