6S Lithium Battery Charging Protection Board -25.2V 15A

Specifications of 6S Lithium Battery Charging Protection Board -25.2V 15A

• Upper limit operating current: 14A (pay attention to heat dissipation)
• Upper limit instantaneous current: 20A
• Balance current: 156mA
• Overcharge voltage range: 4.25V ± 0.05V
• Over-discharge voltage range: 2.7V ± 0.05V
• Quiet current:<30uA
• Charging voltage: 25. 2V-26V
• Short circuit protection: capable of protection, delayed self-recovery
• Board size: 34_53. 5_3mm

Attention

• Don't mix good batteries with bad batteries!
  The closer the battery capacity/internal resistance is, the better!
  The usage effect of one bad battery = the usage effect of 6 bad batteries
• For discharge products with a current of more than 3A, the battery discharge rate must be 3C and above.
  • Ratio calculation formula:
    For a battery with a rate of 1C, the capacity of 2000 is equal to 2AH1=2A working current.
    3C rate battery, 2000 capacity is equal to 2AH3=6A working current.

The battery will heat up during use, which means the battery rate is not suitable. In this case, it cannot be used for a long time, and the battery will be damaged quickly.

Precautions using 6S Lithium Battery Charging Protection Board -25.2V 15A

• Lithium battery protection board can not be used for lithium iron phosphate battery, xenon lamp, hand drill battery pack, electric fish battery pack, electric bicycle battery pack, baby car battery, 550 or more power motor, 1W fisheye LED lamp, Customers who purchase in the above combination should pay attention to the following products: the massager battery pack, LED light backup power supply, 12V electronic products, solar street light battery pack, monitoring standby power supply, and other products.
• For discharge products above 3A, the discharge rate of the battery should be more than 3C. Magnification formula: 1C rate battery, 2000 capacity equals 2AH*1=2A working current, 3C rate battery, 2000 capacity equals 2A*3=6A working current. In use, the battery will heat up or the battery rate is not applicable. The battery will be damaged quickly after long-term use.
• After connecting the line, you need to charge first to have output.
• When connecting 6 sets of batteries in series, please ensure that the voltage of each set of batteries is the same. If they are different, please fill each set of batteries separately and use them in series. During the discharge test, the battery with the fastest voltage drop is the poor battery.
• Do not mix good battery and poor battery! The closer the internal resistance of the 6-cell battery is, the better! (The effect of 4 good batteries + 2 poor batteries = the effect of 6 poor batteries)
