The XKT203-50 Pulse High Voltage Inverter is a high-power ignition module designed with the advanced XKT-205 IC. This module boasts a simple circuit and high output power, making it ideal for applications requiring adjustable high voltage and efficiency. It operates on a standard 24V power supply but can function within a 12V to 30V range. The output voltage reaches approximately 25KV, suitable for various high-power ignition applications.
Specifications of XKT203-50 Pulse High Voltage Inverter
- Module Size: 28x20xmm
- Power Supply Voltage: 12V to 30V (standard 24V)
- Power Supply Current: ≥ 5A
- Output Voltage: ~25KV
- Discharge Distance: 20mm to 25mm
- Output Power: ~120W at 24V, ~150W at 30V
- Operation Voltage: 12V-30V
- Operation Current: ≥ 5A
- Dimensions: 28x20xmm
How to use the XKT203-50 Pulse High Voltage Inverter
- Power Connection: Connect the module to a power supply within the range of 12V to 30V. Ensure the current is greater than or equal to 5A for optimal performance.
- Output Adjustment: Adjust the output voltage as needed to achieve the desired discharge distance and power.
- Heat Dissipation: Note that the module has a small heat dissipation device and is not designed for prolonged use. To extend operation time, increase the heat dissipation area as necessary.
- Safety Precautions: Handle with care, ensuring proper insulation and safety measures due to the high output voltage.
