WS2811 LED RGB Breakout Module
$0.26
Availability:
SKU
SEN-11-033
+100 4 % $0.25 |
+500 8 % $0.24 |
+1000 12 % $0.23 |
+5000 12 % $0.23 |
+10000 15 % $0.22 |
Description
The WS2812 is actually an RGB LED with a WS2811 built right into the LED! All the necessary pins are broken out to 0.1″ spaced headers for easy bread-boarding. Several of these breakouts can be chained together to form a display or an addressable string.
Pin Description
5V:This should be a regulated supply voltage between 5V and about 7V. More than that could harm the LED, less than 5V will either reduce brightness, or it just won’t turn on.
GND:The common, ground, 0V reference supply voltage.
DI:Data from a microcontroller (or another WS2812 pixel) comes into this pin.
DO:Data is shifted out of this pin, to be connected to the input of another pixel or left floating if it is the last link in the chain.
