TCS34725 RGB Color Sensor Module

TCS34725 RGB Color Sensor Module is a digital color sensing module for RGB and clear light measurements. It includes an IR blocking filter to reduce the IR spectral component of incoming light and support accurate color measurements. The module provides a wide dynamic range and is suitable for use under varying lighting conditions and through attenuating materials. It also includes an ambient light sensor function. This module uses the TCS34725 chip and I2C communication.

Features of TCS34725 RGB Color Sensor Module - I2C, 3.3V To 5V

• RGB and clear light sensing
• IR blocking filter
• Wide dynamic range
• Ambient light sensing
• I2C communication

Specifications of TCS34725 RGB Color Sensor Module - I2C, 3.3V To 5V

• Chip: TCS34725
• Voltage: 3.3 to 5V DC
• Communication protocol: I2C IIC 7-bit address 0x29
• IR blocking filter
• Suitable for industrial use
• Weight: 3/3 grams
• Dynamic range: 3,800,000
• Programmable high and low thresholds with persistence filter
• Minimum sleep power: 5 microamp
• Data rate: up to 400 kilobytes per second
• Separation of red, green, and blue light
• Ambient light sensor
• Output type: Digital
• Detection distance: 3mm to 10mm
• Interface: I2C
• Pin number: 7 Pins

How to Use TCS34725 RGB Color Sensor Module - I2C, 3.3V To 5V

1. Connect the module to a compatible I2C circuit.
2. Power the module within the specified voltage range.
3. Read the RGB, clear, and ambient light values.

More Info

• 7-pin header is included, un-soldered.
• Suitable for product color verification and sorting.
• Useful for ambient light and RGB LED backlight control.
