Volume discounts:
- +100 4 % $0.1250
- +500 6 % $0.1220
- +1000 8 % $0.1200
- +5000 10 % $0.1170
- +10000 12 % $0.1150
Shop with confidence
Learn More
Availability:
SKU
S1-0070
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress on orders over $35.
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
$0.1300
SPX3819M5-L-3-3/TR, LDO Voltage Regulator, SOT-23-5 is available to buy in increments of 10
The SPX3819M5-L-3-3/TR is a low-noise linear voltage regulator (LDO) that provides a fixed 3.3V output voltage with a maximum output current of 500mA. This regulator features a low dropout voltage (maximum 0.7V at 500mA) and low quiescent current (90µA), making it ideal for portable applications and low-power devices. Additionally, the IC includes protections against overcurrent, overtemperature, and reverse polarity.
Specifications of SPX3819M5-L-3-3/TR Low-Noise Linear Voltage Regulator
- Input Voltage: Up to 16V
- Output Voltage: Fixed 3.3V
- Output Current: Up to 500mA
- Dropout Voltage: Maximum 0.7V at 500mA
- Quiescent Current: 90µA
- Package: SOT-23-5
- Features: Protection against overcurrent, overtemperature, and reverse polarity
| Package | SOT-23-5 |
|---|---|
| Packaging | Tape & Reel |
| Operating Temperature Min | -40 C° |
| Operating Temperature Max | +125 C° |
| Polarity | Positive Type |
| Mounting Type | SMD/SMT |
| Components - Type | LDO Voltage Regulators |
