OpenBCI Cyton Biosensing EEG Board (8-channels)
$4900.0000
In stock
SKU
SEN-21-045
Volume discounts:
- +5 5 % $4650.0000
- +10 8 % $4525.0000
- +25 10 % $4400.0000
- +50 13 % $4275.0000
- +100 15 % $4150.0000
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping
Free delivery in 7-10 days by Express Shipping
More shipping info
Shop with confidence Learn More
OpenBCI Cyton + Daisy Biosensing EEG Boards (16-Channels) Previous
The OpenBCI Cyton Biosensing Board is an Arduino-compatible 8-channel bio-amplifier designed for EEG, EMG, and ECG applications. Powered by a PIC32MX250F128B microcontroller, it offers fast processing, 24-bit resolution, and wireless communication via RFduino. The board supports both active and passive electrodes and is ideal for researchers and developers.
Specifications of Cyton Biosensing Board
- Channels: 8 differential high-gain, low-noise input channels
- Microcontroller: PIC32MX250F128B with chipKIT™ bootloader
- ADC: Texas Instruments ADS1299, 24-bit resolution
- Radio Module: RFduino™ Low Power Bluetooth™
- Sampling Rate: 250Hz per channel
- Programmable Gain: 1, 2, 4, 6, 8, 12, 24
- Operating Voltage (Digital): 3.3V
- Operating Voltage (Analog): ±2.5V
- Input Voltage: ~3.3V to 12V (Do not exceed 6V battery)
- Accelerometer: LIS3DH
- Micro SD Slot: Included
- GPIO Pins: 5 pins (3 analog capable)
- Communication: Wireless via OpenBCI USB dongle
Manufacture of Cyton Biosensing Board
| Platform | Arduino |
|---|---|
| Interface Type | Wireless |
| Operating Voltage (V) | 3.3V, ±2.5V |
| Output Type | Wireless |
| Resolution | 24-bit |
| Biometric Parameter | EEG, ECG, EMG |
| Application | EEG,EMG,ECG |
| Sensor Type | Active EEG sensors |
