NEO-7N Flight Control GPS Module With SMA ANT Connector

The NEO-7N Flight Control GPS Module With SMA Connector is a GPS module for flight control and navigation applications. It uses the UBLOX NEO-7N GPS chip for accurate and reliable positioning data. The SMA connector supports an external antenna connection to improve signal reception. This module supports GPS and QZSS positioning systems. It is designed with a UART interface for integration with flight control systems and microcontrollers. The module operates from 3.3V to 5V and has a compact 39x25.5mm size.

Features of NEO-7N Flight Control GPS Module With SMA Connector

• UBLOX NEO-7N GPS chip
• Supports GPS and QZSS
• UART interface
• SMA connector for external antenna
• High sensitivity positioning
• Compact 39x25.5mm size
• 3.3V to 5V operation

Specifications of NEO-7N Flight Control GPS Module With SMA Connector

• GPS Chip: UBLOX NEO-7N
• Positioning Systems: GPS and QZSS
• Operating Voltage: 3.3V to 5V
• Interfaces: UART
• Sensitivity: High sensitivity
• Antenna Connector: SMA connector
• Dimensions: 39x25.5mm
• Accuracy: High positioning accuracy with fast time-to-first-fix and low power consumption

How to Use NEO-7N Flight Control GPS Module With SMA Connector

1. Connect the module to a compatible system through the UART interface.
2. Attach an external antenna using the SMA connector if required.
3. Supply power within the 3.3V to 5V range.

More Info

• Suitable for flight control and navigation applications.
• Designed for GPS-dependent devices.
