TDA2030A 18W Audio Amplifier Board Module
$0.6000
In stock
SKU
SEN-17-021
Volume discounts:
- +50 5 % $0.5700
- +100 7 % $0.5600
- +300 8 % $0.5500
- +500 10 % $0.5400
- +1000 13 % $0.5200
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
XH-M181 PAM8610 Stereo Amplifier Board - 2x15W Class D Previous
TDA2030A 18W Audio Amplifier Board Module is a mono audio amplifier board module for speaker and audio input connections. It uses the TDA2030A audio power amplifier chip and is designed for 18W mono amplification. The board includes a 10K adjustable resistance for amplification level adjustment. It also provides a speaker terminal and a power indicator. The working voltage is 6 to 12V. Board size is 32x24x25mm.
Features of TDA2030A 18W Audio Amplifier Board Module
- TDA2030A audio power amplifier chip
- 18W mono amplifier circuit
- 10K adjustable resistance
- Speaker terminal included
- Power indicator included
- Direct audio signal input
Specifications of TDA2030A 18W Audio Amplifier Board Module
- Chip: TDA2030A
- Circuit design: Mono amplifier 18W
- Working voltage: 6 to 12V
- Adjustable resistance: 10K
- Dimensions: 32x24x25mm
- Speaker terminal: Yes
- Power indicator: Yes
- Board size: 31.6mm x 23.2mm
How to Use TDA2030A 18W Audio Amplifier Board Module
- Connect the audio signal to the input pins.
- Connect the speaker terminal.
- Apply power within the 6 to 12V working range.
- Adjust the 10K resistance to set the amplification level.
More Info
- Mono audio amplifier board module
- Hi-Fi audio output
| Interface Type | Analog |
|---|---|
| Operating Voltage (V) | 6-12V |
| Dimensions (mm) | 32x24x25 |
| Audio Function | Amplifier |
| Output Power | 18W |
| Speaker Impedance (Ω) | 4Ω, 8Ω |
| Input Types | Analog |
| Bluetooth Ver. | No |
| Output Type | Analog |
| Channels | 1-channel |
| Chipset | TDA2030A |
