MKS SERVO57D NEMA17 Closed Loop Stepper Motor Driver

[MTR-09-029]
Shop with confidence Learn More
Availability: In stock
SKU
MTR-09-029
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress on orders over $35.
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
As low as $18.25

Note: The motor is not included with the driver.

The MKS SERVO57D is a NEMA17 closed-loop stepper motor driver designed for high-performance motion control in applications such as CNC machines and 3D printers. With advanced features like RS485/CAN communication options, low noise, and low vibration, this driver ensures smooth and precise operation. Its compact design and robust capabilities make it an excellent choice for demanding automation projects.

Specifications of MKS SERVO57D NEMA17 Closed-Loop Stepper Motor Driver

  • Microprocessor: N32L403 (Cortex-M4)

  • MOSFET: AP30H80Q (30V, 70A)

  • Encoder: 14-bit magnetic encoder

  • Working Voltage: 12V-24V

  • Working Current: 0-5200mA

  • Maximum Speed: 3000 RPM+

  • Subdivision: 1-256 (default 16)

  • Pulse Signal Frequency: 160KHz

  • Pulse Signal Common: Positive

  • Update Frequency:

    • Torque: 20KHz

    • Velocity: 20KHz

    • Position: 20KHz

  • Motor Vibration: Low

  • Motor Noise: Low

  • Motor Temperature: Low

  • Communication Option: RS485/CAN

  • Dimensions: 52.2x52.25mm

Development Resources of MKS SERVO57D

Manufacturer's Product Page
