MAX30102 Heart-Rate Sensor Module
$15.9500
In stock
SKU
SEN-22-007
Volume discounts:
- +25 4 % $15.3100
- +50 6 % $14.9900
- +100 8 % $14.6700
- +300 10 % $14.3500
- +500 12 % $14.0300
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
MAX30102 Heart Rate and Oximeter Sensor Module Previous
The MAX30102 Heart-Rate Sensor Module is a heart-rate sensor module with serial output for real-time monitoring. It is designed for accurate measurements and practical integration in electronics projects. The module supports AT Command control and provides an alarm output voltage of 0 or 3.3V. It includes a measuring range of 20~200 beats/min and an oxygen measuring range of 50~100%. This module operates from a 5V supply and is suitable for use across a wide operating temperature range.
Features of MAX30102 Heart-Rate Sensor Module - 5V, Serial Output
- Serial output
- AT Command control
- 20~200 beats/min measuring range
- 50~100% oxygen measuring range
- Alarm output voltage: 0 or 3.3V
Specifications of MAX30102 Heart-Rate Sensor Module - 5V, Serial Output
- Operating Temperature: -40-+85℃
- Mounting hole spacing: 23x16mm (L x W)
- Supply Voltage: 5V
- Command: AT Command
- Measuring range: 20~200 beats/min
- Oxygen measuring range: 50~100%
- Outputs: Serial output
- Alarm output voltage: 0 or 3.3v
How to Use MAX30102 Heart-Rate Sensor Module - 5V, Serial Output
- Connect the module to a 5V supply.
- Use the serial output and AT Command interface for operation.
- Read the heart-rate and oxygen measurements from the output.
More Info
- Compact sensor module format.
- Mounting hole spacing is 23x16mm (L x W).
| Interface Type | UART |
|---|---|
| Operating Voltage (V) | 5V |
| Operating Temp (°C) | -40 to 85 |
| Dimensions (mm) | 23x16mm |
| Mounting Type | Screw holes |
| Output Type | UART |
| Biometric Parameter | Heart Rate, SpO2 |
| Medical Certification | Consumer Grade |
| Application | healthcare,fitness,wellness |
| Detection Range | 20-200 beats/min |
| Sensor Type | PPG |
