LM2577 DC-DC Step Up Boost Module with Voltage Display
$1.6200
In stock
SKU
BAT-02-025
Volume discounts:
- +50 4 % $1.5500
- +100 7 % $1.5100
- +300 9 % $1.4800
- +500 11 % $1.4400
- +1000 13 % $1.4100
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
LM2596 Constant Current Buck-Boost Power Supply Module Previous
LM2577 DC-DC Step Up Boost Module With Voltage Display is a non-isolated boost module with a 3-digit LED display. It provides adjustable DC output voltage and includes a built-in voltmeter for input and output voltage display. The compact module is designed for practical use in electronics and power supply projects. It operates as a DC-DC step-up power supply module with clear voltage monitoring. The module uses a 3-digit LED display and supports easy output adjustment.
Features of LM2577 DC-DC Step Up Boost Module With Voltage Display
- 3-digit LED display
- Built-in voltmeter
- Adjustable output voltage
- Non-isolated boost design
- Compact size
- Easy output adjustment
Specifications of LM2577 DC-DC Step Up Boost Module With Voltage Display
- Input Voltage: DC 3.5V-34V
- Output Voltage: DC 4V-35V
- Maximum Input Current: 3A
- Maximum Output Current: 2.5A
- Maximum Power: 10W
- Operating Temperature: -40°C to 85°C
- Dimensions: 65x35 mm
- Frequency: 52 kHz
How to Use LM2577 DC-DC Step Up Boost Module With Voltage Display
- Connect the input power within the supported voltage range.
- Adjust the potentiometer until the output voltage changes to the desired level.
- Use the display to monitor input and output voltage.
More Info
- Blue color.
- Durable PCB board and hard plastic materials.
- If the output voltage stays equal to the input voltage, rotate the multi-turn potentiometer until the output changes.
