HJR-4102-L Relay - 5V
$0.2500
In stock
SKU
REL-01-031
Volume discounts:
- +100 4 % $0.2400
- +500 8 % $0.2300
- +5000 12 % $0.2200
Product Variations:
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
SLA-12VDC-SL-A Relay - 12V, 30A Previous
The HJR-4102-L Relay is a 5V DC relay with a 6-pin SPDT contact structure. It is designed as an electrical switching component and circuit protection device. The relay includes a black body made from plastic and metal. Contact material is AgNi-Au. It is fully sealed against environmental particle penetration and uses RT III (IP67) protection. This relay is suitable for applications that require switching between circuit states.
Features of HJR-4102-L Relay - 5V, 6 Pin, SPDT
- 5V DC coil voltage
- 6-pin design
- SPDT contact type
- Sealed construction
- AgNi-Au contact material
Specifications of HJR-4102-L Relay - 5V, 6 Pin, SPDT
- Model: HJR-4102-L
- Coil Voltage: 5V DC
- Load: 3A 120 AC
- Load: 3A 24V DC
- Pin Count: 6 Pin
- Contact: SPDT
- Material: Plastic, Metal
- Color: Black
- Weight: 19 g
- Switching voltage: 240 VAC
- Switching voltage: 60 VDC
- Switching capacity: 360 VA
- Input Voltage DC: 5V
- Internal resistance (Ri): 5V=125 Ohm
- Internal resistance (Ri): 12V=720 Ohm
- Internal resistance (Ri): 24V=2800 Ohm
- Nominal current: 3 A / 24 VDC
- Nominal current: 3 A /120 VAC
- Max switching current: 5 A
- Input Power (operation): 0.2W
- Pin Number: 6 Pin
- Contact element material: AgNi-Au
- Protection class: RT III (IP67)
How to Use HJR-4102-L Relay - 5V, 6 Pin, SPDT
- Connect the 5V DC coil to the control side.
- Wire the SPDT contacts to the switching circuit.
- Apply the specified load within the listed ratings.
More Info
- Relay functions as an electrical switch and circuit protector.
- Fully sealed construction helps protect against dust and moisture.
- Use within the listed electrical ratings.
| Operating Voltage (V) | 5V |
|---|---|
| Dimensions (mm) | 18.4 x 10.2 x 15.3 |
| Mounting Type | THT |
| Control Type | Relay (Electromechanical) |
| Channel Count | 1 |
| Switching Capacity | 3A 120VAC, 3A 24VDC |
| Load Current (A) | 3A |
| Chipset | HJR-4102-L |
| Relay Type | Relay output |
| Display Type | None |
| Material | Metal + Plastic |
| Input Type (AC/DC) | DC |
| Weight (g) | 19 |
| Pins | 6 |
