CJMCU-3216 AP3216 Ambient Light And Proximity Sensor
$1.9600
In stock
SKU
SEN-11-055
Volume discounts:
- +50 4 % $1.8800
- +100 7 % $1.8300
- +300 9 % $1.7900
- +500 11 % $1.7500
- +1000 13 % $1.7100
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
Raspberry Pi Camera Module - 8 Megapixel , 1080p Previous
CJMCU-3216 AP3216 Ambient Light And Proximity Sensor is a digital ALS and PS module with an ambient light sensor, a proximity sensor, and an IR LED in one package. It is designed for ambient light measurement and short-distance proximity detection. The module supports use under transparent or dark glass. It provides digital output for sensor reading applications. This sensor is suitable for mobile, display, and panel-based electronics projects.
Features of CJMCU-3216 AP3216 Ambient Light And Proximity Sensor
- Ambient light sensing
- Proximity sensing
- IR LED included
- Digital output
- High sensitivity on darkened glass
- Anti-flicker rejection
- High ambient light suppression
- Cross talk compensation
Specifications of CJMCU-3216 AP3216 Ambient Light And Proximity Sensor
- Chip: AP3216C
- Input Voltage: 2.8V ~ 3.8V
- Output Type: Digital
- ADC: 16 bit (ALS), 10 bit (Proximity)
- Interface: I2C (Fast Mode)
- Pin Number: 6 Pin
- Operating Temperature: -30°C ~ +85°C
- Storage Temperature: -40°C ~ +85°C
- Size: 15.49mm x 17.91mm
- Working Voltage: 3.3V
- Interface Speed: I2C up to 400 kHz
- Temperature Comparator Circuit: Yes
- Operating Temperature: -30°C to +80°C
- Ambient Light Sensor: 16-bit effective linear output (0~65535)
- Dynamic Range: 4 user-selectable dynamic range
- Proximity Detection: 10-bit effective linear output (0~1023)
- Output Current: 4 programmable IR LED current output
- Anti-flicker Feature: Yes
How to Use CJMCU-3216 AP3216 Ambient Light And Proximity Sensor
- Connect the module to an I2C-compatible system.
- Provide the required supply voltage.
- Read ambient light and proximity output values from the device.
More Info
- Suitable for transparent or dark glass applications.
- Available for mobile and tablet projects, notebook and ultrabook systems, LCD/PDP TV backlight systems, digital photo frames, and capacitive touch panel applications.
| Interface Type | I2C |
|---|---|
| Operating Voltage (V) | 3.3V |
| Operating Temp (°C) | -30°C to +80°C |
| Output Type | I2C |
| Accuracy | 16-bit (0~65535), 10-bit (0~1023) |
| Sensing Method | Optical |
| Chipset | AP3216C |
| Sensor Model | AP3216 |
