Waveshare 0.95 inch RGB SPI OLED Display Module
$11.9500
Out of stock
SKU
LCD-01-121
Volume discounts:
- +25 7 % $11.0700
- +50 9 % $10.8500
- +100 11 % $10.6300
- +300 13 % $10.4200
- +500 15 % $10.2000
Shop with confidence Learn More
Waveshare 0.91 inch OLED I2C Display Module (B) Previous
The Waveshare 0.95 Inch RGB SPI OLED Display Module is a compact color OLED display module for electronics and robotics projects. It uses the SSD1331 driver chip and an SPI interface for display communication. The module features a 0.95inch display size with 96×64 resolution and 65K colorful output. It offers a visible angle of more than 160°. The operating voltage is 3.3V / 5V, and it is designed for hardware platforms such as Raspberry Pi, Jetson Nano, Arduino, and STM32.
Features of Waveshare 0.95 Inch RGB SPI OLED Display Module - 96×64, 3.3V/5V
- SSD1331 driver chip
- SPI interface
- 96×64 resolution
- 0.95inch display size
- 65K colorful display
- Visible angle greater than 160°
- 3.3V / 5V operating voltage
- Hardware platform support
Specifications of Waveshare 0.95 Inch RGB SPI OLED Display Module - 96×64, 3.3V/5V
- Driver chip: SSD1331
- Interface: SPI
- Resolution: 96×64
- Display size: 0.95inch
- Colors: 65K colorful
- Visible angle: >160°
- Operating temp. (℃): -20~70
- Storage temp. (℃): -30~80
- Operating voltage: 3.3V / 5V
- Applicability: Hardware platforms such as Raspberry Pi/Jetson Nano/Arduino/STM32
- Pin 1: VCC
- Pin 1 description: Power positive (3.3~5V power input)
- Pin 2: GND
- Pin 2 description: Ground
- Pin 3: NC
- Pin 3 description: NC
- Pin 4: DIN
- Pin 4 description: Data input
- Pin 5: CLK
- Pin 5 description: Clock signal input
- Pin 6: CS
- Pin 6 description: Chip selection, low active
- Pin 7: D/C
- Pin 7 description: Command signal, low level for command, high level for data
- Pin 8: RES
- Pin 8 description: Reset signal, low active
- Development resource: Wiki
- Wiki: www.waveshare.com/wiki/0.95inch_RGB_OLED_(B)
- Description: 0.95inch RGB OLED, SPI interface, straight/vertical pinheader
How to Use Waveshare 0.95 Inch RGB SPI OLED Display Module - 96×64, 3.3V/5V
- Connect the module to a compatible hardware platform.
- Wire the power, ground, and SPI signal pins as needed.
- Use the driver and development resources to initialize the display.
More Info
- Straight/vertical pinheader
- Development resource available via Wiki
| Platform | Arduino Mega, Arduino Uno, Arduino Nano, Raspberry Pi 3, Raspberry Pi 4, Raspberry Pi 5 |
|---|---|
| Display Size | 0.95 |
| Display Size Range | 0.99 inch and smaller |
| Display Resolution | 96×64 |
| Display Driver | SSD1331 |
| Display Interface | SPI |
| Panle Type | PM OLED |
| Display Color Type | Full Color |
| Touchscreen Type | None |
| Backlight Type | None |
| Viewing Angle (°) | >160° |
| Operating Temp (°C) | -20 to 70 |
| Operating Voltage (V) | 3.3V, 5V |
| Pins | 8 |
