ZVS Tesla Coil Induction Power Supply Module
$4.2500
In stock
SKU
misc-04-045
Volume discounts:
- +25 4 % $4.0800
- +100 6 % $3.9900
- +300 8 % $3.9100
- +500 10 % $3.8200
- +1000 12 % $3.7400
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
ZVS Induction Heating Power Supply Module - DC 5V-12V Previous
The ZVS Tesla Coil Induction Power Supply Module is a power supply module designed for Tesla coil applications. It operates with a DC 12V-30V input range, and less than 12V does not work. The module supports adaptive working frequency control from 30KHz-50Kz. Its output varies with the input power conditions and is specified with clear current and voltage requirements. Board size is also provided for installation planning.
Features of ZVS Tesla Coil Induction Power Supply Module
- DC 12V-30V operation
- Adaptive 30KHz-50Kz working frequency
- Arc length of 1-5 cm
- High-voltage output support
- Compact board size
Specifications of ZVS Tesla Coil Induction Power Supply Module
- Working current: DC 12V-30V (less than 12V does not work)
- Power requirements: 12V ≥ 5A / 15V or more ≥ 10A (the higher the current, the more power)
- Working frequency: 30KHz-50Kz adaptive
- Arc length: 1-5 cm
- Output voltage / power: when inputting 12V/5A, the output is about 10000V 60W; when inputting 24V/10A, the output is about 20000V 200W
- Maximum power: 180-360W
- Board size: 75*70.6mm
How to Use ZVS Tesla Coil Induction Power Supply Module
- Provide a DC input within the 12V-30V working range.
- Meet the stated power requirements for the selected input voltage.
- Use the module within the specified frequency and power limits.
More Info
- Less than 12V does not work.
- The higher the current, the more power.
| Operating Voltage (V) | 12V-30V |
|---|---|
| Operating Current (mA) | 5000 - 15000 mA |
| Dimensions (mm) | 75 x 71 x 18 mm |
| Mounting Type | Screw holes |
| IP Rating | None |
| Converter Type | Inverter (DC-AC) |
| Input Voltage (V) | 12V-30V |
| Output Voltage (V) | 10000V - 20000V |
| Power Rating (W) | 180W - 360W |
| Isolation | Non-isolated |
| Iout Adjustable | No |
| Cooling | Proper cooling |
| Application | Metal melting,Workshops,DIY projects,Small industrial use,Research,Education |
| Vout Adjustable | No |
| Component Type | Power Supply Module |
| Model Number | ZVS Tesla Coil Driver |
