XD-203 Multifunction Arduino Shield
$1.7500
In stock
SKU
ARD-02-065
Volume discounts:
- +50 4 % $1.6800
- +100 6 % $1.6400
- +300 9 % $1.6000
- +500 10 % $1.5700
- +1000 13 % $1.5300
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
Arduino Mega Sensor Shield Expansion Board Previous
XD-203 Multifunction Arduino Shield is a multifunction laboratory shield for Arduino projects. It is suitable for both beginner and advanced users. The XD-203 Multifunction Arduino Shield supports Arduino Uno and Leonardo boards. It includes a 4-digit, 7-segment display, 4 LED status levels, and 3 separate buttons. It also provides DS18B20 and LM35 temperature sensors, an infrared receiver, and a buzzer for testing. The shield supports a Bluetooth module, sound module, and voice recognition module, and it offers a servo interface for different servo motors. It operates from a 5V supply and comes in a compact 70x50x20mm size.
Features of XD-203 Multifunction Arduino Shield
- Supports Arduino Uno and Leonardo
- 4-digit, 7-segment display
- 4 LED status levels
- 3 separate buttons
- DS18B20 and LM35 temperature sensors
- Infrared receiver included
- Buzzer for testing
- Bluetooth module support
- Sound module support
- Voice recognition module support
- Servo interface support
Specifications of XD-203 Multifunction Arduino Shield
- Model: XD-203
- Compatibility: Arduino Uno and Leonardo boards
- Display: 4-digit and 7-segment
- LED: 4 LED levels
- Buttons: 3 separate buttons
- Sensors: DS18B20 and LM35
- Infrared receiver: For receiving commands from a remote control
- Buzzer: For experiments
- Wireless connections: Bluetooth module, sound module, and voice recognition module
- Servo interface: For connecting different servo motors
- Supply voltage: 5V
- Dimensions: 70x50x20mm
How to Use XD-203 Multifunction Arduino Shield
- Connect the shield to an Arduino Uno or Leonardo board.
- Install and configure the required sensors and modules for your project.
- Use the buttons and LED indicators to view different device states.
More Info
- Suitable for control and monitoring projects
- Useful for wireless communication and remote control projects
| Interface Type | Digital, Analog |
|---|---|
| Operating Voltage (V) | 5V |
| Dimensions (mm) | 70x50x20mm |
| Mounting Type | Plug-in shield |
| Function | Development Board |
| IP Rating | None |
| Chipset | XD-203 |
| Qty | 1 |
| LED Color | Red |
| Sensor Type | Infrared Receiver, DS18B20, LM35 |
