WiFi Smart Power Meter with Temperature Controller 10A
The WiFi Smart Power Meter with Temperature Controller 10A (Model: S1W) is a versatile device designed to monitor power consumption and control connected devices efficiently. It supports different temperature sensors (Normal NTC, Waterproof NTC, Metal NTC) for varied applications. With a 2.4-inch HD display, it provides real-time energy usage data, voltage, and current information. The device supports remote control, timing, and protection features, making it ideal for smart homes.
Specifications of WiFi Smart Power Meter with Temperature Controller 10A
-
Model: S1W
-
Material: ABS + PC
-
Measuring Voltage: AC 85-265V
-
Measuring Current: 0-10A (Max 16A, 3680W)
-
Internal Relay: 10A (2650W)
-
Power: Max 3680W
-
Energy Measurement Range: 0 ~ 1999kWh
-
Accuracy: ±1%
-
Wireless Consumption: <0.3W
-
Frequency: 50 / 60Hz
-
Power Factor: 0-1.00PF
-
Working Temperature: -10°C ~ +60°C
-
WiFi Frequency: 2.412 ~ 2.484 MHz
-
Working Humidity: <80%
-
Security Type: WEP64 / WEP128 / TKIP / CCMP (AES)
-
Screen Type: 2.4-inch TFT-LCD HD Display, 240 × RGB × 320 Dot-matrix
-
Date Function: Month/Day
-
Dimensions: 133 x 76 x 73 mm
-
Weight: 160g
Features of WiFi Smart Power Meter with Temperature Controller 10A
-
Remote control and timer function via Tuya/Smart Life App
-
Over-current, over-voltage, and over-power protection
-
Countdown and cycle timing functions
-
Energy measurement with electricity bill calculation
-
Supports Amazon Alexa, Google Home, and SmartThings
-
Real-time power consumption monitoring with large screen digital display
-
Only supports 2.4G Wireless Network
Development Resources of WiFi Smart Power Meter with Temperature Controller 10A
Datasheet: Not available
