SMA Male To SMA Female Straight Adapter
$0.9000
In stock
SKU
CAB-01-167
Volume discounts:
- +50 4 % $0.8600
- +100 7 % $0.8400
- +300 9 % $0.8200
- +500 11 % $0.8000
- +1000 13 % $0.7800
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
SMA Male To MCX Male Straight Adapter Previous
SMA Male To RPSMA Male Adapter is a connector adapter for matching SMA and RPSMA interfaces in electronic and RF assemblies. It provides a straight adapter format with an A connector and a B connector. The body features a gold-plated finish. This adapter is specified with 50 ohm impedance and includes the technical details listed below.
Features of SMA Male To RPSMA Male Adapter
- SMA male connector
- RPSMA male connector
- Gold-plated body
- 50 ohm impedance
- Nickel plated brass body
- Gold plated brass contact
- TFE insulator
- Nickel plated brass ferrule
- 0-11000MHz frequency range
- 1500V voltage breakdown
- 2500V RMS dielectric strength
- Less than 0.15dB insertion loss
- -50 to +85 oC temperature range
Specifications of SMA Male To RPSMA Male Adapter
- Connector A: SMA male
- Connector B: RPSMA male
- Impedance: 50 ohm
- Body: gold plated
- Body: nickel plated brass
- Contact: gold plated brass
- Insulator: TFE
- Ferrule: nickel plated brass
- Frequency Range: 0-11000MHz
- Voltage Breakdown: 1500V
- Dielectic Strength: 2500V RMS
- Insetion Loss: <0.15dB
- Temperature: -50 to +85 oC
How to Use SMA Male To RPSMA Male Adapter
- Connect the SMA male side to the matching SMA interface.
- Connect the RPSMA male side to the matching RPSMA interface.
More Info
- Straight adapter format
- Suitable for connector conversion between SMA and RPSMA interfaces
