Quectel EC800G 4G IoT CAT1 Module with GPS Positioning

Quectel EC800G 4G IoT CAT1 Module with GPS Positioning is a cellular module for IoT applications that combines 4G LTE connectivity with built-in GPS positioning. It is designed for data transmission and location tracking in connected systems. The module supports multiple mobile network technologies and several data communication protocols. It also provides UART, USB, and GPIO interfaces for integration with external devices and sensors. Its low power consumption and compact size make it suitable for space-constrained IoT designs.

Features of Quectel EC800G 4G IoT CAT1 Module with GPS Positioning

• 4G LTE CAT1 connectivity
• Built-in GPS positioning
• Multiple satellite system support
• UART, USB, and GPIO interfaces
• Low power consumption

Specifications of Quectel EC800G 4G IoT CAT1 Module with GPS Positioning

• LTE Cat 1
• GSM/GPRS/EDGE: 850, 900, 1800, 1900 MHz
• WCDMA
• HSPA+
• LTE-FDD: 850, 900, 1800, 2100 MHz
• LTE-TDD: 1900, 2000, 2300, 2500, 2600 MHz
• WiFi: 2.4 GHz 11b (Rx)
• BT: No
• GPS
• GLONASS
• BeiDou
• Galileo
• TCP/IP
• UDP/IP
• FTP
• HTTP
• VoLTE
• Circuit-switched voice calls
• UART
• USB
• GPIO
• SIM card interface
• GNSS antenna interface
• Power supply voltage: 3.3V
• Power supply voltage: 4.2V
• Low power consumption
• Operating temperature
• CE
• FCC
• GCF
• RoHS
• 41 x 30 mm

How to Use Quectel EC800G 4G IoT CAT1 Module with GPS Positioning

1. Connect the module to your system through the available UART, USB, GPIO, SIM card, or GNSS antenna interfaces as needed.
2. Provide a supported power supply voltage within the 3.3V to 4.2V range.
3. Configure the cellular and GPS functions according to your IoT application.

More Info

• Suitable for IoT connectivity and location tracking.
• Compact form factor for space-limited projects.
