P100-2 Liquid Level Sensor- Float Switch
SAVE
As low as $3.7500
In stock
Only %1 left
SKU
SEN-20-021
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
P25 Liquid Level Sensor- Float Switch Previous
The P100-2 Liquid Level Sensor - Float Switch is a dependable and versatile sensor designed to monitor liquid levels in a wide range of applications. It comes in two models, ZP10010-2 and ZP10010-2-52, offering flexibility depending on specific requirements. The sensor features a polypropylene (PP) body, ensuring durability and longevity in various liquid environments. With a high insulation resistance and a sturdy resistive load capacity, this float switch is ideal for applications in water tanks, industrial containers, and more. Its compact design and ease of installation make it suitable for both residential and commercial use.
Specifications of P100-2 Liquid Level Sensor - Float Switch
-
Contact Capacity: 10W
-
Switching Voltage: AC/DC 110V
-
Switching Current: 0.5A
-
Insulation Resistance: >10Ω
-
Contact Resistance: <100mΩ
-
Resistive Load: 10⁷ times
-
Operating Temperature: -10°C to +60°C
-
Working Pressure: <0.6MPA
-
Medium Specific Gravity: >0.6
-
Switch Material: Polypropylene (PP)
-
Color Options: White, Red, Black
-
Thread Diameter: 10mm (Approx.)
-
Switch Body Size: 23 x 114 mm (Max D*H)
| Operating Voltage (V) | 110V |
|---|---|
| Operating Temp (°C) | -10°C to +60°C |
| Dimensions (mm) | 23 x 114 mm (Max D*H) |
| Mounting Type | M10 Thread |
| Output Type | Digital |
| Environmental Parameter | Liquid Level |
| Probe Type | Immersion |
| Chipset | ZP10010-2 |
| Relay Output | No |
