Micro Momentary Tactile Push Button - 12x12 mm

Micro Momentary Tactile Push Button is a compact push-button switch for electronic projects and small boards. It has 4 pins, with two pins connected together in pairs. The switch is normally open and returns to its original state after the pressure is released. Its 12x12 mm size makes it suitable for compact designs and easy mounting with DIP leads.

Features of Micro Momentary Tactile Push Button - 12x12 mm, 12V DC, 50mA

• Momentary push-button action
• Normally open switch
• 4-pin connection
• Compact 12x12 mm size
• DIP leads for easy mounting

Specifications of Micro Momentary Tactile Push Button - 12x12 mm, 12V DC, 50mA

• Size: 12x12 mm
• Height: Different heights
• Voltage: Up to 12V DC
• Current: 50mA
• Pins: 4
• Self-resetting after release

How to Use Micro Momentary Tactile Push Button - 12x12 mm, 12V DC, 50mA

1. Place the switch on the board using the DIP leads.
2. Connect the four pins to the circuit as required.
3. Press the button to close the circuit.
4. Release the button to return it to the original state.

More Info

• Suitable for electronic and mechanical devices.
• Can be used in calculators and push-button telephones.
• Can be used in kitchen appliances and home or commercial equipment.
