L7805CV, Linear Voltage Regulator IC, TO-220

$0.1400
In stock
SKU
S1-0051
Volume discounts:
  • +100 4 % $0.1350
  • +500 6 % $0.1320
  • +1000 8 % $0.1290
  • +5000 9 % $0.1270
  • +10000 11 % $0.1240
L7805CV, Linear Voltage Regulator IC, TO-220 is available to buy in increments of 10
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress on orders over $35.
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
Shop with confidence Learn More
TP4065, Battery Management IC, SOT-23-5 Previous TP4065, Battery Management IC, SOT-23-5

The L7805CV is a three-pin linear voltage regulator IC that provides a fixed 5V output, packaged in TO-220. This regulator can supply output current up to 1.5A and features protection against thermal overload and short-circuit conditions. These features make it suitable for use in various circuit applications.

Specifications of L7805CV Voltage Regulator IC

  • Output Voltage: 5V
  • Output Current: Up to 1.5A
  • Input Voltage: 7V to 35V
  • Package: TO-220
  • Dimensions: 10.16 x 4.57 mm
More Information
Package TO-220
Packaging Tube
Operating Temperature Min 0 C°
Operating Temperature Max +125 C°
Polarity Positive Type
Mounting Type Through Hole
Components - Type Linear Voltage Regulators
