E18-D50NK 30cm Adjustable Induction Switch
$3.2500
In stock
SKU
SEN-19-022
Volume discounts:
- +25 4 % $3.1200
- +100 6 % $3.0500
- +300 8 % $2.9900
- +500 10 % $2.9200
- +1000 12 % $2.8600
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
The E18-D50NK Adjustable Induction Switch is a photoelectric sensor with an adjustable measuring distance. It is designed for accurate detection of transparent and opaque objects. The switch includes a built-in LED indicator and a durable metal housing. Its compact form supports easy installation in automation and control systems. The E18-D50NK Adjustable Induction Switch operates with a 5Vdc input and supports a wide working environment range.
Features of E18-D50NK Adjustable Induction Switch
- Photoelectric working principle
- 0-50cm adjustable measuring distance
- Built-in LED indicator
- Metal housing
- Detects transparent and opaque objects
Specifications of E18-D50NK Adjustable Induction Switch
- Working principle: Photoelectric
- Measuring distance: 0-50cm adjustable
- Max Input voltage: 30v
- Wires: Brown - positive, blue - negative, black - data
- Input: 5Vdc
- Current consumption: 200mA
- Working environment: temperature -40 to +70 degrees Celsius
- Protection level: IP61-IP67
- Corresponding time: the function reset time is below 2.5MS
- Detecting objects: transparent & opaque
- Weight: 65g
How to Use E18-D50NK Adjustable Induction Switch
- Connect the brown wire to positive, the blue wire to negative, and the black wire to data.
- Apply a 5Vdc input within the allowed operating conditions.
- Adjust the measuring distance as needed for the application.
More Info
- Protection level: IP61-IP67
- Function reset time is below 2.5MS
- Working environment temperature: -40 to +70 degrees Celsius
| Interface Type | Digital |
|---|---|
| Operating Voltage (V) | 5-24V |
| Operating Current (mA) | 200mA |
| Operating Temp (°C) | -40 to +70 degrees Celsius |
| Mounting Type | Panel Mount |
| Output Type | Digital |
| Response Time | < 2.5MS |
| Detection Distance | 0-50cm adjustable |
| Sensing Method | Infrared (IR) |
| Weight (g) | 65g |
| Chipset | E18-D50NK |
| Max Output (A) | 200mA |
| Sensor Model | E18-D50NK |
| Signal Indicator | Signal output indicator |
