ADS1015 16-Bit 4-Channel ADC Analog Digital Converter Module
$1.0400
In stock
SKU
COM-05-062
Ships in 2-3 business days, then:
Free delivery in 12-15 days by Tracked Economic Shipping on orders over $100.
Free delivery in 7-10 days by Express Shipping on orders over $300.
More shipping info
Shop with confidence Learn More
ADS1115 4-Channel 16-Bit ADC Module for Raspberry Pi Previous
The ADS1015 16-Bit 4-Channel ADC Converter Module is a compact analog-to-digital converter module for microcontroller projects. It provides 16-bit precision and communicates through I2C. The module can be configured as 4 single-ended input channels or 2 differential channels. It operates with 2V to 5V power and logic. A programmable gain amplifier up to x16 is included for signal adjustment.
This ADC module is suitable for designs that need external analog-to-digital conversion over a simple two-wire bus. Its address can be changed to one of four options, allowing multiple modules on a single I2C bus. The module is presented on a breakout board with ferrites for quieter AVDD and AGND lines.
Features of ADS1015 16-Bit 4-Channel ADC Converter Module - I2C, 2V-5V
- 16-bit ADC precision
- I2C communication
- 4 single-ended input channels
- 2 differential channels
- Programmable gain amplifier up to x16
- 2V to 5V power and logic
- Adjustable I2C address
- Breakout board with ferrites
Specifications of ADS1015 16-Bit 4-Channel ADC Converter Module - I2C, 2V-5V
- Product type: ADC converter module
- Precision: 16-bit
- Interface: I2C
- Input channels: 4 single-ended
- Input channels: 2 differential
- Programmable gain amplifier: up to x16
- Power: 2V to 5V
- Logic: 2V to 5V
- Address options: four
- Board type: breakout board
- Ferrites: included
How to Use ADS1015 16-Bit 4-Channel ADC Converter Module - I2C, 2V-5V
- Connect the module to the microcontroller through I2C.
- Apply 2V to 5V power and logic.
- Select the input channel configuration and gain setting.
- Read the converted digital data through I2C.
More Info
- The I2C address can be changed to one of four options.
- Up to four modules can share a single two-wire I2C bus.
| Interface Type | I2C |
|---|---|
| Operating Voltage (V) | 2V to 5V |
| Operating Current (mA) | 0.15mA |
| Operating Temp (°C) | -40 to 85 |
| Dimensions (mm) | 27.6mm x 17mm |
| Mounting Type | Soldering |
| Interface Category | I2C Serial Interface Board Module |
| Output Type | I2C |
| Channels | 4-channel |
| Chipset | ADS1015 |
| Voltage Range | ±0.256V to ±6.144V |
| Protocols | I2C |
| Conversion Type | Analog to Digital |
