7805, Linear Voltage Regulator IC, SOT-89
$0.1500
In stock
SKU
S1-0121
7805, Linear Voltage Regulator IC, SOT-89 is available to buy in increments of 10
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress on orders over $35.
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
Shop with confidence
Learn More
The 7805 is a fixed 5V linear voltage regulator IC designed to provide a stable output voltage from a higher input voltage source. Packaged in a compact SOT-89 form, it's ideal for space-limited applications. Commonly used in power supplies for electronic circuits, it offers built-in protection features such as thermal shutdown and current limiting.
Specifications of 7805, Linear Voltage Regulator IC, SOT-89
- Output Voltage: 5V fixed
- Input Voltage Range: 7V to 25V
- Operating Current: Quiescent current approx. 5 mA
- Output Current: Up to 100 mA (SOT-89 version)
- Dropout Voltage: Typically 2V
- Protection: Thermal shutdown and short-circuit protection
- Mounting Style: Surface Mount
- Package/Case: SOT-89
- Dimensions: 4.5x2.5x1.5mm
Datasheet of 7805, Linear Voltage Regulator IC, SOT-89
