THDZ-1625 Piezoelectric Passive Buzzer

THDZ-1625 Piezoelectric Passive Buzzer is a passive buzzer for sound output and simple melody generation. It requires an AC signal to produce sound and does not generate sound with DC voltage. The buzzer can be driven directly from 3V to 5V using Arduino or a microcontroller. It is supplied with male pin leads. This model is designed for 4 kHz resonant operation and a square-wave input.

Features of THDZ-1625 Piezoelectric Passive Buzzer - 4KHz

• Passive buzzer design
• AC signal operation
• 3V to 5V drive support
• Male pin leads
• 4 kHz resonant frequency
• Square-wave input

Specifications of THDZ-1625 Piezoelectric Passive Buzzer - 4KHz

• Type: THDZ-1625
• Voltage: 12Vp-p square wave
• Operating voltage: 1-30 volts
• Maximum current: 5 mA
• Minimum output sound: 80 dB
• Resonant frequency: 4 kHz
• Operating temperature: -20 to 70 degrees Celsius
• Size: 16x20 mm

How to Use THDZ-1625 Piezoelectric Passive Buzzer - 4KHz

1. Connect the buzzer to a compatible driving circuit or controller.
2. Apply a square-wave signal within the operating voltage range.
3. Use the signal to produce sound or a simple melody.

More Info

• DC voltage does not produce sound.
• The input signal determines the sound tone.
• Male pin leads are included.
