ULN2804, Darlington Transistor, DIP-18
$0.2050
In stock
SKU
S3-0007
Volume discounts:
- +100 4 % $0.1970
- +500 6 % $0.1930
- +1000 8 % $0.1890
- +5000 10 % $0.1850
- +10000 11 % $0.1820
ULN2804, Darlington Transistor, DIP-18 is available to buy in increments of 10
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress on orders over $35.
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
Shop with confidence
Learn More
ULN2003, Darlington Transistor, DIP-16
Previous
The ULN2804 transistor is a high-voltage, high-current driver designed to control electromechanical loads such as relays and DC motors. It contains 8 NPN transistors integrated into a single DIP-18 package. It also features protections against overload and reverse current.
Specifications of ULN2804 High-Voltage, High-Current Driver Transistor
- Package: DIP-18
- Number of Channels: 8
- Input voltage: 5V to 30V
- Output current per channel: 500mA (max)
- Operating temperature range: -40°C to +85°C
| Package | DIP-18 |
|---|---|
| Packaging | Tube |
| Operating Temperature Min | -20 C° |
| Operating Temperature Max | 85 C° |
| Polarity | NPN Type |
| Mounting Type | Through Hole |
| Components - Type | Darlington Transistors |
