PCF8563 Real Time Clock RTC Module
$0.6500
In stock
SKU
misc-03-005
Volume discounts:
- +100 6 % $0.6100
- +300 8 % $0.6000
- +500 9 % $0.5900
- +1000 11 % $0.5800
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress on orders over $35.
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
Shop with confidence
Learn More
DS3231 Real Time Clock RTC Module for Raspberry Pi
Previous
Description
The PCF8563 is a CMOS1 Real-Time Clock (RTC) and calendar optimized for low power consumption. A programmable clock output, interrupt output, and a voltage-low detector is also provided. All addresses and data are transferred serially via a two-line bidirectional I 2C-bus. The maximum bus speed is 400 kbit/s. The registered address is incremented automatically after each written or read data byte.
Specifications
Alarm and timer functions
Integrated oscillator capacitor
Internal Power-On Reset (POR)
I2C-bus slave address: read A3h and write A2h
Open-drain interrupt pin
Features
Provides the year, month, day, weekday, hours, minutes, and seconds based on a 32.768 kHz quartz crystal
Chip:Â PCF8563
Clock Operating Voltage: 1.0V ~Â 5.5V (at room temperature)
Current: 0.25μA (at VDD = 3.0 V and Tamb = 25 „)
Interface: I2C
Programmable clock output for peripheral devices: 32.768KHz, 1.024KHz, 32Hz, and 1Hz
Pin Number: 6 Pin
Size: 18mm x 25mm
