Heartbeat Pulse Sensor Module
$68.9500
In stock
SKU
SEN-22-004
Volume discounts:
- +5 4 % $66.3500
- +10 6 % $65.0600
- +25 8 % $63.7600
- +50 9 % $62.4600
- +100 11 % $61.1600
Ships in 2-3 business days, then:
Free delivery in 10-15 days by YunExpress
Free delivery in 5-7 days by DHL on orders over $200.
More shipping info
Shop with confidence
Learn More
Heart Rate Pulse Sensor Module
Previous
EasyPulse sensor module is designed for entertainment and educational applications. And it is used as a non-invasive technique to demonstrate the law of plethysmography (PPG) to detect the cardiovascular pulse wave through the fingertip. This module uses a transmission mode sensor probe (PPG (HRM-2511E). And an infrared light source for irradiating the finger on one side and a light detector on the other side for measuring the smallest changes in transmitted light intensity due to changes in the amount of blood within the tissue.The equipment provides a smooth and filtered analog PPG waveform plus a digital pulse output so that both are synchronized with the heartbeat.
Specifications:
- PPG stable output signal
- MCP6004 op-amp based on precision measurement with rail-to-rail output capability for maximum output signal swing
- It has separate analog and digital output
- Has gain control potentiometer for analog output
- Has bandwidth control for digital output
- Additional test point on the board for signal analysis in different stages of measurement
- Can be started at 3.3V and 5V voltage
